Technical Specificaons : Model Dimension Power Power Weight (L x W x H) Consumption About 280g (No Power Adapter) SY-GPON-1110- WDONT 185mm×120mm× 32mm 12V,1A ≤9W Specificaons : Parameter Name Hardware Parameter CPU 400MHz Memory 128M bytes DDR3 Flash 128M NAND PON Port Type Optical module PON GPON, SC single mode, GEPON, SC Single Mode (Dual mode) Upstream 1.25Gbps, Downstream 2.5Gbps. single-fiber Wavelength Tx 1310nm, Rx 1490nm Sensitivity <-7dBm(CLASS B+) Overload >-8dBm(CLASS B+) Optical Type SC/PC LAN interface 1*10/100/1000Mbps, 1*100Mbps Auto adaptive Ethernet interfaces, Full/Half Duplex, RJ45 connector 1POTS, RJ11 connector Wireless IEEE802.11b/g/n, 300Mbps, 2T2R Parameter : Parameter Name Hardware Parameter SY-GPON-1110-WDONT Internet connection Bridge / Routing LAN Support Port rate limiting
