The INNO View M7 is an ultra-portable active V-groove clad alignment fusion splicer optimized for FTTH (Fiber to the Home) and vertical cabling projects. As of 2026, it is highly regarded for its compact design, weighing only 1.56 kg with the battery.
Key Technical Specifications
The M7 is designed for speed and reliability in confined field environments:
Splicing Speed: Typically 7 to 9 seconds (Quick Mode vs. Typical). The newer M7+ model can reduce this to 4 seconds.
Heating Time: Fast heating between 13 to 15 seconds for standard sleeves.
Battery Life: Equipped with a 3000mAh battery (LBT-3000) providing approximately 130 to 200 splice/heat cycles per charge, depending on power-save settings.
Electrode Life: Long-lasting electrodes rated for 5, 500 arc discharges.
Fiber Magnification: Features outstanding 400X magnification and resolution on a high-definition screen.
Display: 4.3-inch color LCD capacitive touchscreen with an intuitive smartphone-like interface.
Advanced Field Features
Active V-Groove Alignment: Uses four precision motors to align fiber cladding, compensating for environmental factors better than standard fixed V-groove machines.
Ruggedized & Versatile: Built with a ceramic clamp for improved durability and includes 2 bright LEDs for working in dark environments.
Customizable Ergonomics: Features an adjustable strap hanger, allowing technicians to secure the machine to their bodies or workstations for hands-free or awkward-angle splicing.
SOC Compatibility: Includes a detachable heat oven specifically for Splice-On Connectors (SOC), essential for modern network terminations.
Market Availability & Pricing (2026)
In early 2026, the INNO M7 is available in India through various industrial suppliers:
Estimated Price: Ranges from approximately ₹1, 05, 000 to ₹1, 42, 000 depending on the specific kit and merchant.
Standard Kit: Usually includes a high-precision cleaver (like the V1), battery, power adapter, carrying case (ICC-50), and spare electrodes.
Support: Typically backed by a 2-year to 3-year warranty.
