The Deviser AE1001 is an ultra-portable Mini Optical Time Domain Reflectometer (OTDR) specifically engineered for installing and maintaining FTTx networks. It is distinguished by its lightweight, handheld design and integrated testing suite, making it a 'zero-fuss' tool for field technicians.
Core Technical Specifications
As of early 2026, the AE1001 is characterized by the following performance parameters:
Test Wavelengths: Dual 1310nm (±20nm) and 1550nm (±20nm).
Dynamic Range: 26 dB at 1310nm and 24 dB at 1550nm.
Testing Speed: Results are generated in as little as 5 seconds.
Dead Zones: Event dead zone of ≤ 3 meters and attenuation dead zone of ≤ 10 meters.
Measurement Range: Capable of testing fiber spans up to 80 km. Integrated Testing Features
The AE1001 is an all-in-one fiber characterization tool:
Optical Power Meter (OPM): Standard measurement range of -70 to +10 dBm (with options for high-power ranges up to +26 dBm).
Visual Fault Locator (VFL): Built-in 650nm (1 mW) laser for identifying breaks or bends.
Storage: 16 GB internal memory capable of holding over 160, 000 traces.
Modes: Supports Auto, Manual, and Real-time testing modes with onboard auto-analysis.
Design and Portability
Display: 4.3-inch TFT LCD color touchscreen, optimized for visibility in both high- and low-light conditions.
Weight: Extremely lightweight at less than 1 kg (2.2 lbs).
Battery: 2500 mAh Li-ion battery providing up to 6 hours of operating time and ~4 hours of continuous testing.
Connectivity: Features USB 2.0 for data export and an optional RJ45 LAN port.
